• Features
  • Large LCD screen, easy to read
  • Laser plumb line for easy above-ground installation
  • Lighting on the screen and field of view
  • Horizontal circle: Hold function, 0-set at any desired position, clockwise/counterclockwise reading
  • Vertical circle: reading in gon / degrees / percent

• Technical specifications
  • Magnification: 30x
  • Clear lens diameter: 45mm
  • Shortest focus distance: 1.5 m
  • Angle measurement absolute decoder
  • Accuracy: 20“ (6 mgon)
  • Minimum reading: 10“ (3 mgon)
  • Measurement units: 400 gon / 360°
  • Laser plumb bob: measuring point size Ø 2mm at 1.5m
  • Laser plumb: laser class 2
  • Operating time / power supply: 18 hours / NiMH
  • Temperature range: -20°C to +50°C
  • Dust / water protected: IP 54
  • Weight (instrument only): 4.2kg

• Accessories included
  • Tripod
  • Rechargeable battery
  • Charger
  • Battery storage for alkaline
  • Batteries
  • Bag

>>
